Trigger Cycle Timer Delay Switch Circuit Board Dual MOS Tube Control Module DC 5?36V

Item Type: Trigger Cycle Timer <br>Material: PCB <br>Uses: Commonly used to control motors, bulbs, LED strips, DC motors, miniature water pumps, solenoid valves, etc. <br>Working Voltage: DC 5V--36V <br>Trigger Signal Source: High-level trigger (DC 3.0V-24V), the signal ground and the system ground are not in the same ground to improve the anti-interference ability of the system (also can be short-circuited to the common ground) <br>Output Capacity: DC 5V--36V, continuous current 15A at room temperature, power 400W. Under auxiliary heat dissipation conditions, the maximum current can reach 30A <br>Quiescent Current: 15mA <br>Service Life: Unlimited switch <br>Working Temperature: -40~85℃ <br>Size: Approx. 6.0 x 3.4 x 1.2cm / 2.4 x 1.3 x 0.5in<br>1、Realize the high-frequency fast and frequent on-off of the circuit, unlimited switching times, no noise during the on-off process, no electric spark, no electromagnetic interference, and the service life is longer than that of common electromagnetic relays <br>2、Using dual MOS parallel active output, lower internal resistance, higher current, strong power, 15A, 400W at room temperature, which meets the use of most equipment <br>3、Mainly used to control motors, light bulbs, LED strips, DC motors, micro water pumps, solenoid valves, etc. Wide voltage operation (5~36V) can easily control these devices through this module, which is very convenient <br>4、Clear and simple interface, powerful, easy to understand, and meets almost all your needs <br>5、Come with one key emergency stop function (STOP key), with reverse connection protection, reverse connection does not burn 6、Adding sleep mode , automatically turn off the display without any operation within 5 minutes, any key to wake up after enabling 7、You can be set different OP, CL, LOP parameters, these parameters are independent of each other and saved separately; all setting parameters are automatically saved when power off1 x Trigger Cycle Timer
