Condition: Brand New Item Type: Digital Video Recorder Material: Metal Color: As picture System: Main Processors: Industrial-grade Embedded Chip Hi3520D V300 Video: Codec Standard: H.265 Surveillance Quality: VGA, for HDMI HD Preview Ability: 8x1080N Coding Ability: 8x1080N@12fps Decoding Capability: 8x1080N@12fps Mode Input: Coaxial: 8x1080N4x1080P Mixed: 2x1080P(coaxial) + 2x1080P (networks); 4x1080N(coaxial)+4x960P(networks) Networks: 16x1080P; 9x1080P; 16x960P; 4x5M Motion Detection: 192 (16 x 12) Detection Areas Can Be Set for Each Screen; Multi-level Sensitivity Can Be Set Degrees (limited to Local Channels) Audio: Audio Compression: G.711A Intercom: Support Video: Recording Method: Manual> Alarm> Dynamic Detection> Timing Video Query: Time Point Search, Calendar Search, Event Search, Channel Search Video Storage: Local Hard Disk, Networks Video Backup: Networks Backup, USB Mobile Hard Disk, USB Burning, SATA Burning Interface: Video Input: 8 Channels BNC Video Output: 1 Channel VGA, 1 Channel for HDMI Loop-Through Output: No Audio I / O: 14/1 Alarm I / O: 0/0 Network Interface: RJ45 10M/100M Adaptive Ethernet Port Expand Interface: 2 USB Interfaces Hard Disk Interface: 1 SATA Interface (Each Supports Up to 8T) Power Supply: 12V/2A Working Environment: Temperature 0 -+ 55 , Humidity: 10% -90%, Atmospheric Pressure: 86kpa-106kpa Package List 1 x Digital Video Recorder 1 x Power Supply 1 x Mouse 1 x Instruction 4 x Mounting Screws 1Support for VGA and for HDMI highdefinition output display. 2Support for ONVIF protocol to connect to third party devices (network mode). 3Support multiple cloud technologies, realize networks penetration, front and back end docking, and push alarm information to mobile phones. 4Supporting Web, CMS, central platform management software for MYEYE, and providing SDK development. 5Support remote monitoring of various mobile phones and ipads(for ios, for android). 6Remote access, with its own domain name service function (ARSP), oneclick to enable remote monitoring. 7Standard coaxial control, easy to achieve the back end control front end. 8Support AHD / TVI / CVI / CVBS / PVI / IP signal 6in1 access. 9The networks mode supports "Full Netcom", compatible with all major brands of IPC, crossedsegment, and onekey networking with the same IP.
