Item Type: Linear Stage Manual Fine?Tune Platform_x000D_Body Material: Aluminum Alloy (black anodized)_x000D_Color: Black_x000D_Model: HBLX-A60_x000D_Table Surface Size: Approx. 40x60mm/1.6x2.4in_x000D_Product Overall Height: Approx. 130mm/5.1in_x000D_Moving Direction: AZ-axis, 2 directions_x000D_Movement Method: Rotating gears and rotating handles to advance_x000D_Sliding Track: Gear guide_x000D_Rail Type: Dovetail groove type_x000D_Number Of Countertop Threaded Holes: 8pcs_x000D_Threaded Hole Diameter: Approx. 4mm/0.2in_x000D_Threaded Hole Depth: Approx. 6mm/0.2in_x000D_Withstand Load: 49N (5Kgf)_x000D_Up and Down Movement Stroke: 20mm_x000D_Minimum Scale: Approx. 0.01mm/0.0004in_x000D_Moving Parallelism: 0.05mm/13mm_x000D_Structure: Detachable_x000D_Application: Optical equipment, measuring devices, semiconductor manufacturing equipment, testing machines, microscopes, photographic equipment, handling machines, processing machines, medical machines, printing machines and others._x000D__x000D_How to Use: _x000D__x000D_1. The mechanical sliding table is a general component that completes the feed movement. The complete mechanical sliding table is composed of the sliding table part and its moving common parts, the complete mechanical sliding table part and other moving device brakes and other auxiliary parts. According to the process requirements of the machined parts, a power box (with multi-axis box) drilling head, boring head, milling head, boring head, turning head, etc. are installed on it to form various combined machine tools to complete drilling and expansion. , Reaming, scraping end face, chamfering, turning end face, milling, drilling and tapping, etc. Deep hole processing can be completed by configuring a graded feed mechanism on the sliding table (the graded feed mechanism is only used for specifications below HJ32)_x000D_2. The sliding table can be installed on the side base or column, and can also be installed on the inclined base to form a horizontal, vertical or inclined combined machine tool.Manual Fine?Tune Platform 1The main body is made of high?quality aluminum alloy, which is light, strong and resistant to friction. 2Quiet, no loud sound when working, scratch?proof, drop?proof, and corrosion?proof. 3Gear rotation handle control, dovetail groove guide, for high accuracy, smoothness, high load resistance and stable movement. 4R angle protection, safety protection, for high practicability and high reliability. 5The surface is treated with black anodic oxidation, which is not easy to rust and can be used for a long time.1 x Sliding Table 1 x Manual
