Item Type: CNC DC?DC Buck Module_x000D_Material: ABS_x000D__x000D_Purpose: Power Supply for Equipment Such As Laboratories of Scientific Research Institutes, Factory Automation Production Lines, Electronic Instrument Maintenance, Etc._x000D__x000D_Input Voltage Range 6-70.00V_x000D_Output Voltage Range: 0-60.00V_x000D_Output Current Range: 0-18.00A_x000D_Output Power Range: 0-1080W_x000D_Output Voltage Setting and Measurement Accuracy: (0.3%+3 Digits)_x000D_Output Current Setting and Measurement Accuracy: (0.5% + 5 Digits)_x000D_Capacity Measurement Range: 0-9999.99ah_x000D_Energy Measurement Range: 0-9999.99wh_x000D_Statistical Error of Capacity and Energy: +2%_x000D_Step-down Working Mode: Differential Pressure>1V And>10%_x000D_Typical Output Ripple: 250mV VPP_x000D_Screen Brightness Setting: 0-5 (6 Levels in Total)_x000D_Display Screen: 2.4-inch Color LSD Display_x000D_Input Voltage Measurement Resolution: 0.01V_x000D_Output Voltage Setting Measurement Resolution: 0.01V_x000D_Current Setting Measurement Resolution: 0.01A_x000D_Battery Voltage Measurement Resolution: 0.01V_x000D_Input Voltage Measurement Accuracy: (1%+5 Digits)_x000D_Battery Voltage Measurement Accuracy: (0.5% + 3 Digits)_x000D_Constant Voltage Mode Response Time: 2ms (0.1A-5A Load)_x000D_Load Adjustment Rate in Constant Voltage Mode: (0.1%+2 Digits)_x000D_Constant Current Mode Load Adjustment Rate: (0.1% + 3 Digits)_x000D_Product Working Temperature Range: -10-40_x000D_Temperature Measurement Range of External Probe: -10-100/0-200_x000D_Temperature Measurement Error of External Probe: 3/+6 1Support setting output, switch control and panel key lock. The screen is bigger, clearer and more intuitive, 2.4?inch color LCD display. Button upgrades, convenient operation, combination of numeric keyboard and coding potentiometer, setting more convenient. Wide range of adjustment, small range adjustment. 2Battery charging, one machine with multiple functions, using special battery charging terminals, not afraid of wrong connection, multiple types of battery charging at one time. Data storage function, convenient and efficient, instant storage and recall of set parameters. 3Support curve display, real?time display of the output voltage, current, power curve. 4?digit resolution accurate measurement, continuous optimization of product hardware and software accuracy algorithm layer to ensure product measurement accuracy and stability 4The double insurance is set to facilitate replacement. For no welding experience or welding equipment, a buckle insurance base is specially reserved to facilitate timely replacement after the insurance is blown 5Select high?quality components, made by SMT chip technology, excellent performance, stable and reliable. High accuracy, superior performance, can be used independently or embedded in equipment 6The load is fully protected. The output overvoltage (OVP)/overcurrent (OCP) data can be set by pressing the button. When the output voltage/current exceeds the protection value, the power supply will automatically stop output to prevent damage to the electrical equipment. 7Support for iOS/Android APP, PC host computer, cool interface, remote control, data recording, convenient and quick.1 x CNC DC?DCBuckModule 1 x Fuse 2 x Wiring Terminal 1 x Temperature Sensing Line
